Key Specifications

General Specifications

• Sound system: 11.1.4 channel
• Power supply: 100 - 240V AC, ~ 50/60Hz
• Total speaker power output* (Max. @THD 1%): 2470W
• Soundbar transducer: 8x (50x75mm) racetrack drivers, 7x 1” (25mm) tweeters, 4x 3” (75mm) up-firing full-range drivers
• Surround speaker transducer: 2x (50x90mm) racetrack drivers, 1x 2” (50mm) full-range drivers, 1x 3” (75mm) up-firing full-range drivers
• Subwoofer transducer: 2x 8” (200mm)
• Networked standby power: < 2W
• Lithium battery: 7.2V, 4722mAh
• Detachable surround speaker playtime: up to 10 hours (may vary according to content type and volume level)

HDMI specification

• HDMI video input: 3
• HDMI video output (with Enhanced Audio Return Channel, eARC): 1
• HDMI HDCP version: 2.3
• HDR pass through: HDR10+, Dolby Vision

Audio Specification

• Frequency response: 33Hz - 20kHz (-6dB)
• Audio inputs: Optical, Bluetooth, USB (USB playback is available in US and APAC version. For other versions, USB is for Service only.)

USB specification

• USB port: Type A
• USB rating: 5V DC, 0.5A
• Supporting file formats: mp3

Wireless specification

• Bluetooth version: Main Bar - v5.3, Detachable surround speaker - v5.4
• Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
• Bluetooth transmitter power: <15 dBm (EIRP)
• Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
• 2.4G Wi-Fi transmitter frequency range: 2412 - 2472 MHz (2.4 GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)
• 2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
• 5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470 - 5.725GHz, 5.725 - 5.825GHz
• 5G Wi-Fi transmitter power: 5.15 - 5.25GHz <23dBm, 5.25 - 5.35GHz & 5.470 - 5.725GHz <20dBm, 5.725 - 5.825GHz <14dBm (EIRP)

Dimensions

• Total soundbar dimensions (W x H x D): 1404 x 58 x 136mm / 55.3” x 2.3” x 5.4”
• Soundbar dimensions (W x H x D): 1030 x 58 x 136mm / 40.6” x 2.3” x 5.4”
• Detachable surround speaker dimensions (each) (W x H x D): 202 x 58 x 136mm /8” x 2.3” x 5.4”
• Subwoofer dimensions (W x H x D): 315 x 277 x 275mm /12.4” x 10.9” x 10.8”
• Soundbar weight: 5.93kg / 13lbs
• Detachable surround speaker weight (each): 1.3 kg / 2.8lbs
• Subwoofer weight: 12kg / 26.5lbs
• Packaging dimensions (W x H x D): 1124 x 381 x 452 mm / 44.3” x 15” x 17.8”
• Packaging weight: 28.6kg / 63.1lbs (EMEA/UK) 24.3kg / 53.6lbs (JP/NCN) 28.8kg / 63.5lbs (AU/NZ) 24.5kg / 54.0lbs (APAC Others)



What’s in the box:

• 1x Main soundbar
• 2x Detachable wireless surround speakers
• 1x Wireless subwoofer
• Remote control with 2 x batteries
• Power cords (up to 6pcs depending on region SKUs)
• 1 x HDMI cable
• 2 x L-shape wall-mount bracket (main bar) + 2 x U-shape wall-mount bracket (for surround speakers) kit with screws
• 4 x Side caps
• Quick start guide
• Safety instruction and Warranty card
• Wall mount template
