• Sound system: 7.1.4 channel
• Power supply: 100 - 240V AC, ~ 50/60Hz
• Total speaker power output* (Max. @THD 1%): 960W
• Soundbar output power** (Max. @THD 1%): 500W
• Surround speaker output power*** (Max. @THD 1%): 2x 80W
• Subwoofer output power**** (Max. @THD 1%): 300W
• Soundbar transducer: 6x (44x80)mm racetrack drivers, 2x 1” (25mm) tweeters, 2x 2.75” (70mm) up-firing full-range drivers
• Surround speaker transducer: 2x (44x90)mm racetrack drivers, 2x 2.75” (70mm) up-firing full-range drivers
• Subwoofer transducer: 10” (260mm)
• Lithium battery: 3.635V, 6600mAh
• Detachable surround speaker playtime: up to 10 hours (may vary according to content type and volume level)

• HDMI video input: 3
• HDMI video output (with Enhanced Audio Return Channel, eARC): 1
• HDMI HDCP version: 2.3
• HDR pass through: HDR10+, Dolby Vision

• Frequency response: 33Hz - 20kHz (-6dB)
• Audio inputs: Optical, Bluetooth, USB (USB playback is available in US version. For other versions, USB is for Service only.)

• USB port: Type A
• USB rating: 5V DC, 0.5A
• Supporting file formats: mp3

• Bluetooth version: v5.3
• Bluetooth profile: A2DP v1.3, AVRCP v1.5
• Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
• Bluetooth transmitter power: <15 dBm (EIRP)
• Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
• 2.4G Wi-Fi transmitter frequency range: 2412 - 2472 MHz (2.4 GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)
• 2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
• 5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470 - 5.725GHz, 5.725 - 5.825GHz
• 5G Wi-Fi transmitter power: 5.15 - 5.25GHz <23dBm, 5.25 - 5.35GHz & 5.470 - 5.725GHz <20dBm, 5.725 - 5.825GHz <14dBm (EIRP).

• Total soundbar dimensions (W x H x D): 1203 x 52x 128mm / 47.4” x 2.0” x 5.0”
• Soundbar dimensions (W x H x D): 854 x 52 x 128mm / 33.6” x 2.0” x 5.0”
• Detachable surround speaker dimensions (each) (W x H x D): 189x 52 x 128mm / 7.4” x 2.0” x 5.0”
• Subwoofer dimensions (W x H x D): 325 x 400 x 325 mm / 12.8” x 15.7” x 12.8”
• Soundbar weight: 5.5kg / 12.1 lbs
• Detachable surround speaker weight (each): 0.9 kg / 2 lbs
• Subwoofer weight: 9.1 kg / 20 lbs
• Packaging dimensions (W x H x D): 980 x 398 x 495 mm / 38.58” x 15.67” x 19.49”
• Packaging Weight: 22.6kg / 49.8lbs (EMEA/UK/AU/NZ);19.9kg / 44.4lbs (Others)* RMS @THD 1%: 480W

What’s in the box:

• 1x Main soundbar
• 2x Detachable wireless surround speakers
• 1x Wireless subwoofer
• Remote control with 2 x batteries
• Power cords (up to 6pcs depending on region SKUs)
• 1 x HDMI cable
• 2 x L-shape wall-mount bracket (main bar) + 2 x U-shape wall-mount bracket (for surround speakers) kit with screws
• 4 x Side caps
• Quick start guide
• Safety instruction and Warranty card
• Wall mount template
